The Round Expansion Tank Bracket Kit Steel D42 is a high-capacity solution engineered for commercial and industrial hydronic systems, providing robust support for large expansion tanks in high-pressure, high-vibration environments. With reinforced steel construction and advanced corrosion protection, this kit ensures reliable performance in boiler rooms, district heating networks, and industrial process heating systems.
Heavy-Duty Construction:
Q345B steel (yield strength 345 MPa) with 42mm tube compatibility, supporting 200kg static load and 150kg dynamic load (vibration ≤15G, 5-500Hz).
Kit includes seismic restraint brackets (compliant with ASCE 7-16), adjustable mounting plates, and stainless steel hardware, enabling secure installation in seismic zones (up to 8.0 Richter scale).
Extreme Environment Resistance:
Duplex galvanized finish (100μm thickness) + polyurethane topcoat, passing 1500 hours salt spray test (ASTM B117) and resisting chemical exposure (pH 6-9), ideal for coastal and industrial areas.
Heat-resistant rubber pads (150°C continuous) for proximity to boilers, reducing thermal transfer and protecting tank surfaces from radiant heat.
Precision Installation:
Laser-cut mounting slots (12mm width) allow 80mm horizontal adjustment, with anti-loosening nuts (ISO 7040) ensuring zero displacement in high-vibration settings.
Pre-assembled with a backing plate (6mm thickness) for concrete wall mounting, distributing load over 200x200mm to prevent structural damage.
Compliance & Testing:
Certified to EN 1090-1 (structural steel) and OSHA 1910.119, with magnetic particle inspection on welds and load test reports available for third-party verification.
Temperature rating: -40°C to +120°C, suitable for extreme cold storage and high-temperature boiler rooms.
Suited for heavy-duty heating systems, this bracket kit is used in:
Commercial Boiler Plants: Secures 50-150L tanks in 1-5MW heating systems for office complexes and hotels, with seismic restraints meeting NEI 07-13 for critical infrastructure.
Industrial Process Heating: Mounts pressure vessels in food processing plants and chemical facilities, resisting corrosion from steam and cleaning agents (e.g., caustic soda, citric acid).
District Heating Substations: Supports multiple tanks in large-scale networks, with modular design enabling parallel installations and easy expansion as demand grows.
Power Generation Facilities: Used in cogeneration plants, providing stable support for expansion tanks in combined heat and power systems (CHP) compliant with ISO 13709.
Load-Bearing Leadership: Highest capacity in its class for a kit-based solution, validated by third-party lab tests (report no. IND-2024-003).
Custom Engineering: Offers bespoke seismic kits and heat-shielding options for unique industrial challenges, with 7-day turnaround for custom modifications.
Global Service Network: 24/7 technical support for large projects, including on-site installation supervision and annual maintenance audits.
Longevity Assurance: 10-year warranty on structural components, with corrosion resistance guaranteed for 15 years in industrial environments.
